Operating
70
12. Connect the adapter shaft and the bend arm by the lower and upper support.
Place the lower first, upper support second into position.
WARNING!
Never bend without using the supports! Otherwise strong
forces might cause deformation and damage to the adapter shaft.
Adapter shaft
Bend arm
Upper support
Lower support
