Operating
83
 Press Bending forward. The tube will be bent until the choosen bending
angle is reached.
 Press Mandrel backward. The mandrel will be stroken in back position.
 Press Clamping backward. The clamping cylinder returns to startposition.
 Press Outer support backward. The outer support and the following pressure
die drives back to startposition.
