Table 202 — Guidance and Manufacturer’s Declaration -
Immunity All Equipment and Systems
GUIDANCE AND MANUFACTURER’S DECLARATION - IMMUNITY
AureFlo® is intended for use in the electromagnetic environment specied below.
The customer or user of AureFlo® should ensure that it is used in such an environment.
IMMUNITY TEST EN 60601 TEST LEVEL COMPLIANCE LEVEL
ELECTROMAGNETIC ENVIRONMENT-
GUIDANCE
ESD
EN 61000-4-2
±8kV Contact
±15kV Air
±8kV Contact
±15kV Air
Floors should be wood, concrete or
ceramic tile. If oors are synthetic,
the r/h should be at least 30%.
EFT
EN 61000-4-4
±2kV Mains ±2kV Mains
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
EN 61000-4-5
±1kV Differential
±2kV Common
±1kV Differential
±2kV Common
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage
Dips/Dropout
EN 61000-4-11
100% Dip for 0.5 Cycle
at 0°, 45°, 90°, 135°, 180°,
225°, 270° & 315°
60% Dip for 5 Cycles
100% Dip for 1 Cycle
30% Dip for 25/30
Cycles: Single Phase at 0°
100% Dip for 5 seconds
100% Dip for 0.5 Cycle
at 0°, 45°, 90°, 135°,
180°, 225°, 270° & 315°
60% Dip for 5 Cycles
100% Dip for 1 Cycle
30% Dip for 25/30
Cycles: Single Phase
at 0°
100% Dip for 5
seconds
Mains power quality should be that
of a typical commercial or hospital
environment. The unit will shut
off during the >95% for 5 second
disturbance. If the user of AureFlo
®
requires continued operation during
power mains interruptions, it is
recommended that the AureFlo
®
be
powered from an uninterruptible
power supply or battery.
Power Frequency
50/60Hz
Magnetic Field
EN 61000-4-8
30 A/m 30 A/m
Power frequency magnetic
elds should be that of a typical
commercial or hospital environment.
