Appendix C–14
INSTALLING AND USING ALKALINE BATTERIES
To power the gauge using five AA alkaline batteries, install the
batteries as follows:
Turn the gauge off.
Loosen the four captive screws on the control unit.
Carefully lift the control unit from the gauge.
Unplug the ribbon cable from the control unit.
Install five standard AA alkaline batteries into the battery holder
(see Figure C–2).
Set the battery select switch to the ALKALINE position.
Plug the ribbon cable into the control unit.
Attach the control unit to the gauge with the four captive
screws.
