LUBRICATING THE SOURCE ROD
If the source rod does not slide up and down freely, the source rod
bearing may require lubrication. A grease fitting is located beneath
the top shell at the base of the source rod tower.
✓
Remove the control unit from the gauge by loosening the four
captive screws that secure the control unit to the top shell. Lift
the control unit out of the gauge and disconnect the ribbon
cable.
✓
Locate the grease fitting at the bottom of the source rod tower.
✓
Using a standard 16-oz grease gun loaded with a
Magnalube-G cartridge, apply five shots of lubricant to the
grease fitting.
✓
Re-assemble the control unit.
