Troxler 3430 Plus User Manual

Model 3430 Plus & 3440 Plus
Appendix C–25
Figure C–5. Scaler Assembly, Part Numbers
110791 (3430 Plus) and 110876 (3440 Plus) (Continued)
ITEM
PART #
DESCRIPTION
QTY.
1
110826
BACKPLATE ASSY SCALER
1
2
110802
PANEL ASSY KEYBOARD
1
3
110801
110817
3430 PLUS OVERLAY
3440 PLUS OVERLAY
1
4
110859
RUBBER COVER
1
5
110832
SPST ROCKER SWITCH
1
6
108176
SCALER DISPLAY
1
7
000921.1259
STANDOFF .4"
4
8
003090.0116
16PINROWCONN
1
9
000104.1400
2-56 SCREW
8
10
250129
CPU BOARD ASSY.
1
11
110881
STANDOFF .5"
4
12
110841
SCALER GASKET
1
13
000923.1251
3/8" STANDOFF
3
14
000204.1400
PH SCREW
5
15
000923.2442
.75" STANDOFF
2
16
250137.3440
ASSY CONTROL PCB 3440+
1
17
110825
ON/OFF POWER CABLE
1
C. TROUBLESHOOTING
