Troxler 3430 Plus User Manual

Appendix C–28
Figure C–6. Baseboard Assembly, Part Numbers
110790 (3430 Plus) and 110877 (3440 Plus) (Continued)
ITEM
PART#
DESCRIPTION
QTY.
1
110880
BATTERY HOLDER
1
2
110838
BASEBOARD COVER
1
3
015610.2000
CONTACT STRIP
1
4
110875
USBWIZ COVER
1
5
000204.1101
#4 FH SCREW
2
6
000204.1400
#4 PH SCREW
15
7
000001.0401
#4 INT LOCKWASH
17
8
000923.2442
STANDOFF
4
9
110835
BASEPLATE ASSY
1
10
000923.1251
#4 STANDOFF 3/8
4
11
107854
GM TUBE HOLDER
1
12
102119
PAD
1
13
104094
ASSY, 900V TUBE
1
14
103540
TUBE CLAMP
1
15
000604.1400
#10 PH SCREW
1
16
000001.1000
#10 LOCK WASHER
1
17
102095
HE3 BUMPER PAD
2
18
100156
GM TUBE
2
19
104098
GM TUBE INTFC.
1
20
110250
BASE BOARD ELEC
1
21*
110874
USBWIZ BOARD
1
22
107164
HIGH VOLT ASSY
1
23
000203.1401
#4 SCREW 3/16
2
24
104136
BRACKET
1
25
000306.1401
GM TUBE SCREW
2
26
000206.1400
GM TUBE SCREW
2
* Item 21 is included only on Model 3440 Plus gauges.
