6–16
ENABLE NOMOGRAPH
Press 〈1〉 from the display at the bottom of page 6–15 to enable the
Nomograph function. The display will be:
NOMOGRAPH
ON
The gauge will return to the READY display.
DISABLE NOMOGRAPH
To disable the Nomograph function, press 〈2〉 from the display at the
bottom of page 6–15. The display will be:
NOMOGRAPH
OFF
The gauge will return to the READY display.
CHANGE/VIEW NOMOGRAPH DATA
To change or view the function data, press 〈3〉 from the display at the
bottom of page 6–15. The display will be:
Thickness-
x.xx in.
Press ENTER
when completed
Input the desired overlay thickness. Press 〈START/ENTER〉. The display
is:
Select to set-
1-Bottom dens.
2-Core dens.
(CE to exit)
The wet density of the underlying or base material may be input using one
of two methods: keypad entry or by using the gauge to record actual
measurements.
