TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 97 Copyright 2013 All Rights Reserved.
Message Translation Protocols
 ~#
Description
The beginning identifier (~#) of the prompt message is sent from the printer to the KP-200 portable
keyboard. The ending identifier is ~&. @0 following the ending identifier ~& is used to instruct
keyboard to display the prompt in the first line of LCD display. @1 following the ending identifier ~& is
used to instruct keyboard to display the prompt in the first line of LCD display. If @0 or @1 are not
present, prompt string will be displayed in first line of LCD and input data will be displayed in second
line of LCD.
Syntax
~#Prompt~&[@0]
~#Prompt~&[@1]
Parameter Description
None N/A
Example
Sample code
DOWNLOAD "A.BAS"
OUT "~#KP-200~&@0"
OUT "~#Testing~&@1"
EOP
A
Result
See Also
INPUT, OUT

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
