TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 223 Copyright 2013 All Rights Reserved.
 @MINUTE
Description
This variable reads/writes the minute data via the Real Time Clock (RTC). The two-digits (00~59)
minute format is supported by RTC. @MINUTE global variable can be accessed directly without using
BASIC language functions.
Syntax
Write attribute: @MINUTE = "12"
Read attribute: @MINUTE
Range: 00~59
Model
Support
TTP-243 series
TTP-243 Plus series
V
TTP-244ME series
TTP-244ME Plus series
V
TTP-244 series
V
TTP-244CE series
V
TTP-245 series
V
TTP-245C series
V
TDP-245 series
V
TTP-246M series
V
TTP-248M series
TTP-2410M series
V
TDP-643 Plus
V
TDP-643R Plus
V
TTP-342 series
TTP-342 Plus series
V
TTP-342M series
TTP-342M Plus series
V
TTP-343 series
V
TTP-343C series
V
TTP-344M series
V
TTP-346M series
V
TTP-384M series
V
TTP-644M series
V
M23 series
Example
Sample code
REM *****Set @MINUTE*****
@MINUTE="59"
REM *****Print*****
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
TEXT 10,10,"3",0,1,1,"@MINUTE"
TEXT 210,10,"3",0,1,1,@MINUTE
PRINT 1
Result
See Also
~!C, @YEAR, @MONTH, @DATE, @DAY, @HOUR, @SECOND

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
