TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 107 Copyright 2013 All Rights Reserved.
 KILL
Description
This command deletes a file in the printer memory. The wild card (*) will delete all files resident in
specified DRAM or FLASH memory.
Model
Support
KILL "*"
KILL "*"
MOVE
KILL F,"*"
KILL E,"*"
TTP-243 series
V
V
TTP-243 Plus series
V
V
TTP-244ME series
V
V
TTP-244ME Plus series
V
V
TTP-244 series
V
V
TTP-244CE series
V
V
V
TTP-245 series
V
V
V
TTP-245C series
V
V
V
TDP-245 series
V
V
V
TTP-246M series
V
V
V
TTP-248M series
V
V
V
TTP-2410M series
V
V
V
TDP-643 Plus series
V
V
TDP-643R Plus series
V
V
TTP-342 series
V
V
TTP-342 Plus series
V
V
TTP-342M series
V
V
TTP-342M Plus series
V
V
TTP-343 series
V
V
V
TTP-343C series
V
V
V
TTP-344M series
V
V
V
TTP-346M series
V
V
V
TTP-384M series
V
V
V
TTP-644M series
V
V
V
M23 series
V
V
V
Syntax
KILL [n],”FILENAME”
Parameter
Description
n
Specify the memory location that files will be deleted.
n is ignored: Kill files saved in DRAM.
F: Kill files from main board flash memory.
E: Kill files from expansion memory module.
FILENAME
The name of data file that will delete in the printer memory (case
sensitive)
Note:
 If optional parameter n is not specified, firmware will delete the file in DRAM.
 Syntax example
KILL "FILENAME " : Delete the specify file in DRAM.
KILL "*.PCX " : Delete all PCX files in DRAM.
KILL "* " : Delete all files in DRAM.

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
