TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 141 Copyright 2013 All Rights Reserved.
 INP$( )
Description
One byte is received from communication port.
Syntax
INP$(n)
Parameter
Description
N
1: com1 port in printer
Example
Sample code
DOWNLOAD "TEST.BAS"
T$=""
FOR I=1 TO 5
T$=T$+INP$(1)
NEXT
SIZE 4,0.5
GAP 0,0
CLS
TEXT 10,10,"3",0,1,1,"The received data is: "+T$
PRINT 1
EOP
TEST
12345
Result
See Also
INP()

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
