TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 174 Copyright 2013 All Rights Reserved.
 SET CUTTER
Description
This setting activates or deactivates the cutter and defines how many printed labels is to be cut at one
time. This setting will be saved in printer memory after turning off the power.
Syntax
SET CUTTER OFF/BATCH/pieces
Parameter
Description
OFF
Disable cutter function.
BATCH
Set printer to cut label at the end of printing job.
Pieces
Set number of printing labels per cut. 0<= pieces <=65535
Note:
 Care label cutter module was supported since V6.86 EZ in industrial printer TTP-2410M series.
 Since V6.86 EZ, if cutter is not installed, the cutter error doesn’t happen even SET CUTTER ON is
set.
Example
Sample code
Result
SIZE 3,3
GAP 0,0
SET CUTTER OFF
SET PEEL OFF
CLS
TEXT 50,50,"3",0,1,1,"SET CUTTER OFF"
PRINT 3
The cutter function is disabling.
SET CUTTER BATCH
CLS
TEXT 50,50,"3",0,1,1,"SET CUTTER BATCH"
PRINT 3,2
The cutter cuts once after 6 labels are printed.
SET CUTTER 1
CLS
TEXT 50,50,"3",0,1,1,"SET CUTTER 1"
PRINT 3,2
The cutter cuts every label.
CLS
TEXT 50,50,"3",0,1,1,"SET CUTTER 2"
PRINT 3,2
The cutter cuts every 2 labels.
See Also
OFFSET, PRINT, SET PARTIAL_CUTTER

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
