 INPUT
Description
This command receives data through specific port. This command is used with portable keyboard
KP-200.
Syntax
INPUT ["Prompt string", number of digits], variables
The comma also can be replaced by semicolon, such as:
INPUT ["Prompt string"; number of digits]; variables
Parameter
Description
Prompt string
The prompt string is shown on keyboard LCD screen. The maximum length
of prompt string is 20 characters
Number of digits
Maximum number of characters is 255
Variables
The variable to receive input data
Example
Sample code
DOWNLOAD "TEXT.BAS"
SIZE 4,3
GAP 0,0
DIRECTION 1
:START
INPUT "CODE 39 :",C39$
INPUT "EAN 13:",12,E13$
CLS
TEXT 20,50,"3",0,1,1,"INPUT and KP-200 Test"
BARCODE 20,100,"39",48,1,0,2,5,C39$
BARCODE 20,200,"EAN13",48,1,0,4,4,E13$
PRINT 1
GOTO START
EOP
TEXT
123456
123456789012
Result
See Also
DOWNLOAD, EOP, END, GOTO

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
