TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 184 Copyright 2013 All Rights Reserved.
 SET TEAR & SET STRIPER
Description
This command is used to enable/disable feeding of labels to gap/black mark position for tearing off.
This setting will be saved in printer memory when turning off the power.
Syntax
SET TEAR ON/OFF (TSPL2 language printers only)
SET STRIPER ON/OFF (TSPL language printers only)
Parameter
Description
ON
The label gap will stop at the tear off position after print.
OFF
The label gap will NOT stop at the tear off position after print. The
beginning of label will be aligned to print head.
MODEL
SUPPORT
SET TEAR
SET STRIPER
TTP-243 series
V
TTP-243 Plus series
V
V
TTP-244ME series
V
TTP-244ME Plus series
V
V
TTP-244 series
V
V
TTP-244CE series
V
TTP-245 series
V
TTP-245C series
V
TDP-245 series
V
TTP-246M series
V
TTP-248M series
V
TTP-2410M series
V
V
TDP-643 Plus series
V
TDP-643R Plus series
V
V
TTP-342 series
V
TTP-342 Plus series
V
V
TTP-342M series
V
TTP-342M Plus series
V
V
TTP-343 series
V
TTP-343C series
V
TTP-344M series
V
TTP-346M series
V
TTP-384M series
V
TTP-644M series
V
M23
V
Example
Sample code
REM ***TEAR FUNCTION ON***
SIZE 3,3
GAP 0.08,0
DENSITY 8
SPEED 4
DIRECTION 0
REFERENCE 0,0
SET CUTTER OFF

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
