TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 41 Copyright 2013 All Rights Reserved.
 TLC39
Description
This command draws TLC39, TCIF Linked Bar Code 3 of 9, barcode.
Syntax
TLC39 x,y,rotation,[height,]narrow,]wide,]cellwidth,]cellheight,]"ECI number,Serial number &
additional data"
Parameter
Description
x
Specify the x-coordinate
y
Specify the y-coordinate
rotation
0 : No rotation
90 : Rotate 90 degrees clockwise
180 : Rotate 180 degrees clockwise
270 : Rotate 270 degrees clockwise
height
narrow
wide
cellwidth
cellheight
Height of Code39 in dots (Default is 40)
Width of narrow element of Code39 in dots (Default is 2)
Width of wide element of Code39 in dots (Default is 4)
Width of cell of MicroPDF417 in dots (Default is 2)
Height of cell of MicroPDF417 in dots (Default is 4)
ECI number
Must be 6 digits which is used to generate Code39
Serial number & additional data
Alphanumeric is for Micro-PDF417
Note:
 Comma (") is necessary between ECI number and Serial number & additional data.
 This command has been supported since V6.89 EZ and later firmware.
Example
Sample Code
SIZE 4,1.2
GAP 0,0
DIRECTION 1
CLS
TEXT 10,10,"3",0,1,1,"TLC39 code"
TLC39 10,50,0,"123456,SN00000001,00601,01501"
TLC39 310,50,0,80,3,6,3,4,"123456,SN00000001,00601,01501"
PRINT 1
Result

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
