TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 14 Copyright 2013 All Rights Reserved.
 SHIFT
Description
This command moves the label’s vertical position. A positive value moves the label further from the
printing direction; a negative value moves the label towards the printing direction. For a visual
representation, see next page.
Syntax
SHIFT n
Parameter
Description
n
The maximum value is 1 inch. For 200 dpi printers, the range is –203 to 203; for
300 dpi printers, the range is –300 to 300. The unit is dot.
Model
Support
TTP-243 series
TTP-243 Plus series
V
TTP-244ME series
TTP-244ME Plus series
V
TTP-244 series
V
TTP-244CE series
V
TTP-245 series
V
TTP-245C series
V
TDP-245 series
V
TTP-246M series
V
TTP-248M series
TTP-2410M series
V
TDP-643 Plus series
TDP-643R Plus series
V
TTP-342 series
TTP-342 Plus series
V
TTP-342M series
TTP-342M Plus series
V
TTP-343 series
V
TTP-343C series
V
TTP-344M series
V
TTP-346M series
V
TTP-384M series
V
TTP-644M series
V
M23 series

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
