TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 50 Copyright 2013 All Rights Reserved.
 MAXICODE
Description
This command defines a 2D Maxicode.
Syntax
MAXICODE x,y,mode,[class,country,post,Lm,]"content"
MAXICODE x,y,mode,class,country,postal code,"content"
For mode 2 or 3,
If country is 840, the postal code is in
99999,9999 format.
For other countries, the code is up to
6 alphanumeric characters.
MAXICODE x,y,mode,[Lm,]"content"
For mode 4,5,6,
AIM special format is supported, see
page 23 in the spec.
Mode 6 is not supported in TSPL2
printer firmware.
Parameter
Description
x
X-coordinate of the starting point (in dot)
y
Y-coordinate of the starting point (in dot)
mode
2,3,4,5
class
Class of service, 3-digit number (for mode 2,3)
country
Country code, 3-digit number (for mode 2,3)
post
Post code (for mode 2,3)
Mode 2(USA): 5-digit + 4-digit number
Mode 3(Canada): 6 alphanumeric post code included by double quotes.
Lm
Expression length (double quote is ignored) , 1m138, (this parameter is
just for mode 4 and 5)
content
Content of 2D Maxicode
Note:
If parameter Lm is used, double quotes (") are unnecessary.
Example
Sample code
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
REM *****Mode 2 For USA*****
MAXICODE 110,100,2,300,840,06810,7317,"DEMO 2 FOR USA MAXICODE"
TEXT 100,50,"3",0,1,1,"Mode 2 For USA"
PRINT 1,1

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
