TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 52 Copyright 2013 All Rights Reserved.
 PDF417
Description
This command defines a PDF417 2D bar code.
Syntax
PDF417 x,y,width,height,rotate,[option],"content"
Parameter
Description
x
X-coordinate of starting point (in dot)
y
Y-coordinate of starting point (in dot)
width
Expected width (in dots)
height
Expected height (in dots)
rotate
Rotation counterclockwise
0 : No rotation
90 : Rotate 90 degrees
180 : Rotate 180 degrees
270 : Rotate 270 degrees
option
P
Data compression method
0: Auto encoding
1: Binary mode
E
Error correction level (Range: 0~8)
M
Center pattern in barcode area
0: The pattern will print upper left justified the area
1: The pattern is printed middle of area
Ux,y,c
Human readable
x: Human readable characters in the specified x-coordinate
y: Human readable characters in the specified y-coordinate
c: Maximum characters of human readable character per line
W
Module width in dot (Range: 2~9)
H
Bar height in dot (Range: 4~99)
R
Maximum number of rows
C
Maximum number of columns
T
Truncation
0: Not truncated
1: Truncated
Lm
Expression length, 1m2048 (without " for content)
content
Content of PDF417 2D bar code
Note:
If parameter Lm is used, double quotes (") are unnecessary for content.

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
