TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 63 Copyright 2013 All Rights Reserved.
 QRCODE
Description
This command prints QR code.
Syntax
QRCODE x,y,ECC Level,cell width,mode,rotation,[model,mask,]"content"
Parameter
Description
x
The upper left corner x-coordinate of the QR code
y
The upper left corner y-coordinate of the QR code
ECC level
Error correction recovery level
L : 7%
M : 15%
Q : 25%
H : 30%
cell width
1~10
mode
Auto / manual encode
A : Auto
M : Manual
rotation
0 : 0 degree
90 : 90 degree
180 : 180 degree
270 : 270 degree
model
M1: (default), original version
M2: enhanced version (Almost smart phone is supported by this version.)
mask
S0~S8, default is S7
content
The encodable character set is described as below,
Encodable character set:
1) Numeric data: (digits 0~9)
2) Alphanumeric data
Digits 0-9
Upper case letters A-Z
Nine other characters: space, $ % * + - . / : )
3) 8-bit byte data
JIS 8-bit character set (Latin and Kana) in accordance with JIS X 0201
4) Kanji characters
Shift JIS values 8140
HEX
–9FFC
HEX
and E040
HEX
–EAA4
HEX
. These are
values shifted from those of JIS X 0208. Refer to JIS X 0208 Annex 1
Shift Coded Representation for detail.
Data characters per symbol (for maximum symbol size):
Model 1 (Version 14-L)
Model 2 (Version 40-L)
Numeric data
1,167 characters
7,089 characters
Alphanumeric data
707 characters
4,296 characters
8-bit byte data
486 characters
2,953 characters
Kanji data
299 characters
1,817 characters
* If "A" is the first character in the data string, then the following data
after "A" is alphanumeric data.
*If "N" is the first character in the data string, then the following data
after "N" is numeric data.
*If "B" is the first character in the data string, then the following 4 digits
after "B" is used to specify numbers of data. After the 4 digits is the

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
