TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 163 Copyright 2013 All Rights Reserved.
 TEXTPIXEL( )
Description
Returns the width of the text string in dot.
Syntax
TEXTPIXEL (cont$,font$,size)
Parameter
Description
cont$
The content of text string.
font $
The font type. Please refer to the parameter font in command TEXT.
size
The font size. Please refer to the parameter x-multiplication in command
TEXT.
Note:
This command has been supported since V6.61 EZ and later firmware.
Example
See Also
TEXT, BARCODEPIXEL()
Sample code
DOWNLOAD "TEST.BAS"
str$="ABCDEFG"
font$="3"
fontsize=3
strwidth=TEXTPIXEL(str$,font$,fontsize)
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
TEXT 10,10,font$,0,fontsize,fontsize,str$
REVERSE 8,8,strwidth,72
PRINT 1
EOP
TEST
Result

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
