TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 137 Copyright 2013 All Rights Reserved.
NEXT
TEXT 100,110,"3",0,1,1,"(1) 1+2+3+...+100="+STR$(A)
TEXT 100,160,"3",0,1,1,"(2) 1+3+5+...+99="+STR$(B)
TEXT 100,210,"3",0,1,1,"(3) 2+4+6+...+100="+STR$(C)
TEXT 100,260,"3",0,1,1,"(4) 3+6+9+...+99="+STR$(D)
TEXT 100,310,"3",0,1,1,"(5)
5+10+15+...+100="+STR$(E)
TEXT 100,360,"3",0,1,1," (1)-(5)="+STR$(F)
TEXT 100,410,"3",0,1,1,"(6) 7+14+21+...+98="+STR$(G)
TEXT 100,460,"3",0,1,1,"(7)
17+34+51+...+85="+STR$(H)
TEXT 100,510,"3",0,1,1,"(8) 27+54+...+81="+STR$(J)
TEXT 100,560,"3",0,1,1,"(9) 37+74="+STR$(K)
TEXT 100,610,"3",0,1,1,"
(1)-(6)-(7)-(8)-(9)="+STR$(L)
PRINT 1,1
EOP
DOWNLOAD F,"TEST.BAS"
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
A=85
B=10
:START
IF A<100 THEN GOTO L1 ELSE GOTO L2
:L1
CLS
TEXT 100,10,"3",0,1,1,STR$(A) + " IS SMALLER THEN
100"
PRINT 1
A=A+B
GOTO START
ENDIF
:L2
CLS
TEXT 100,10,"3",0,1,1,STR$(A) + " IS LAGER THEN 100"
PRINT 1
EOP
TEST
Note:
If the result of the expression is nonzero, the statement following THEN will be executed. If the result
of the expression is zero, and the statement following the ELSE is present, it will be executed.
Otherwise the next line of statement is executed.
If there are block of statements in IF…THEN …ELSE, ENDIF must be used at the end of the
IF…THEN …ELSE statement.
Limitations:
The total numbers of nested IF …THEN …ELSE statement in a program cannot exceed 40.

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
