TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 187 Copyright 2013 All Rights Reserved.
TDP-225 series
0~31
0~3
V
Note:
When in “SET HEAD OFF” mode, the function “SET GAP AUTO” doesn’t work even the printer head
is opened and closed, but it can work when power on the printer.
Example
The example below is operated in DOS environment via the parallel port connection to setup the
label size, gap distance and sensor sensitivity.
C:\>COPY CON LPT1<ENTER>
SIZE 4,2.5<ENTER>
GAP 0.12,0<ENTER>
SET GAP 1<ENTER>
<CTRL><Z><ENTER>
C:\>
Note:
<ENTER> stands for keyboard “ENTER” key. In the above example, please press “ENTER” key
instead of typing <ENTER> in the above example. <CTRL> stands for keyboard “Ctrl” key.
Troubleshooting:
Press the FEED key to test. Does printer stop at the same position on each label without the error
light blinking? If not, adjust the setting to a larger number. When adjusting this setting, begin from 0
and then on to higher values incrementally.
See Also
SIZE, GAP, BLINE

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
