TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 65 Copyright 2013 All Rights Reserved.
Example
Sample code
Result
Auto mode example
General data string
SIZE 4,2.5
GAP 0,0
DIRECTION 1
CLS
QRCODE 10,10,H,4,A,0,"ABCabc123"
QRCODE 160,160,H,4,A,0,"123ABCabc"
QRCODE 310,310,H,4,A,0,"印表機 ABCabc123"
PRINT 1,1
Data string including <Enter> character (0Dh, 0Ah)
SIZE 4,2.5
GAP 0,0
DIRECTION 1
CLS
QRCODE 10,10,H,4,A,0,"ABC<Enter>
abc<Enter>
123"
QRCODE 160,160,H,4,A,0,"123<Enter>
ABC<Enter>
abc"
QRCODE 310,310,H,4,A,0,"印表機<Enter>
ABC<Enter>
abc<Enter>
123"
PRINT 1,1
Data string concatenation (Must be used with DOWNLOAD ... EOP
command)
DOWNLOAD “DEMO.BAS”
SIZE 4,2.5
CAP 0,0
DIRECTION 1
CLS
QRCODE 10,10,H,4,A,0,"ABCabc123"+STR$(1234)
QRCODE 160,160,H,4,A,0,"123ABCabc"+"1234"
QRCODE 310,310,H,4,A,0,"印表機 ABCabc123"+"1234"+"abcd"
PRINT 1,1
EOP
DEMO

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
