TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 70 Copyright 2013 All Rights Reserved.
RSS 410,10,"UPCE",0,2,2,"001220000456|ABCDEFG"
PRINT 1
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
REM UPCE Rule 2: 00abc00000ij = abcij3
RSS 10,10,"UPCE",0,2,2,"001230000045|ABCDEFG"
PRINT 1
SIZE 4,1
CLS
REM UPCE Rule 3: 00abcd00000j = abcdj4
RSS 10,10,"UPCE",0,2,2,"001234000005|ABCDEFG"
PRINT 1
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
REM UPCE Rule 4: 00abcde0000j = abcdej where j = 5-9
RSS 10,10,"UPCE",0,2,2,"001234500005|ABCDEFG"
RSS 160,10,"UPCE",0,2,2,"001234500006|ABCDEFG"
RSS 310,10,"UPCE",0,2,2,"001234500007|ABCDEFG"
RSS 460,10,"UPCE",0,2,2,"001234500008|ABCDEFG"
RSS 610,10,"UPCE",0,2,2,"001234500009|ABCDEFG"
PRINT 1
Example of barcode height of EAN8 EAN13 UPCA and UPCE.
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"EAN8",0,1,1,"1234567|ABCDEFG"
RSS 210,10,"EAN8",0,2,1,"1234567|ABCDEFG"
RSS 410,10,"EAN8",0,3,1,"1234567|ABCDEFG"
PRINT 1
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"EAN13",0,1,1,"123456789012|ABCDEFG"
RSS 210,10,"EAN13",0,2,1,"123456789012|ABCDEFG"
RSS 410,10,"EAN13",0,3,1,"123456789012|ABCDEFG"
PRINT 1
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"UPCA",0,1,1,"12345678901|ABCDEFG"
RSS 210,10,"UPCA",0,2,1,"12345678901|ABCDEFG"
RSS 410,10,"UPCA",0,3,1,"12345678901|ABCDEFG"

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
