For font "0", this parameter is used to specify the width (point) of true type
font. 1 point=1/72 inch.
Vertical multiplication, up to 10x
Available factors: 1~10
For true type font, this parameter is used to specify the height (point) of
true type font. 1 point=1/72 inch.
For *.TTF font, x-multiplication and y-multiplication support floating value.
(V6.91 EZ)
Add or delete the space between lines in dot.
Text alignment. (V6.73 EZ)
0 : default (Left)
1 : Left
2 : Center
3 : Right
Data in block. The maximum data length is 4092 bytes.
Note:
The internal font (font #1~#5) pitch between TSPL and TSPL2 is different.
Font “0” and “ROMAN.TTF” internal True Type Fonts are available in TSPL2 language
printers, but not TSPL language printers.
If there is any double quote (") within the text, please change it to \["].
If font "0" is used, the font width and font height is stretchable by x-multiplication and
y-multiplication parameter. It is expressed by pt (point). 1 point=1/72inch.
\[R] means carriage return character 0x0D.
\[L] means line feed character 0x0A.
This command has been supported since V6.91 EZ and later firmware.
EPL2 and ZPL2 are for emulating Eltron
®
and Zebra
®
languages.
Example
Sample Code
SIZE 4,0.5
GAP 0,0
DIRECTION 1
CLS
BOX 10,10,800,100,2
BLOCK 15,15,790,90,"0",0,8,8,"We stand behind our products with one of the most comprehensive
support programs in the Auto-ID industry."
PRINT 1
CLS
BOX 10,10,800,100,2
BLOCK 15,15,790,90,"0",0,8,8,20,2,"We stand behind our products with one of the most
comprehensive support programs in the Auto-ID industry."
PRINT 1
