TSC TTP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 86 Copyright 2013 All Rights Reserved.
Example
Test <ESC>!S by CommTool via RS-232 port.
Result
Item
Meaning
1
The start character of returned value.
2
The 4-byte status in Hex.
3
The end characters of returned value.
4
4-byte status in characters.
@@@@: The printer is normal for use.
F@@@: The printer is feeding label.
`@@@: Printer is in PAUSE mode.
B@@@: The printer is backing label.
E@@B: Printer is in error “Paper Jam”.
E@@b: Printer is in error “Paper Jam” & “Head
open”.
See Also
<ESC>!?
Hex Data 1B 21 53
means <ESC>!S.
The values return
from printer in Hex.
The values return
from printer in
Character.
Click to send Hex
1b 21 53 to query
printer status.
1
2
3
4

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
