Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 2 - 13
7 Conveyor Hand Throttle This knob controls the engine speed only while the
unit is in neutral and the parking brake is applied.
Turn the knob counterclockwise and the engine will
speed up. Depress the hand throttle knob and the
engine will return to idle.
8 Morse Shifter This is the main drive control for forward or reverse
direction. The shifter is labeled: F=Forward,
R=Reverse, and N=Neutral.
9 Code Toggle Switch Press this switch to read fault codes via the diagnos-
tic lamp.
10 Brake Warning Light (Red) This light illuminates if the brake system pressure
falls below a preset level.
11 Emergency Steering Switch This switch activates the emergency steering pump.
Press and hold the switch to start the pump, or
release the switch to stop the pump. The emergency
steering pump activates only if hydraulic pressure is
low.
12 Head Light Switch This switch turns the tractor’s headlights on or off.
Pressing down turns lights off and pressing up turns
lights on.
13 Ignition Switch (Optional
Location)
This switch starts or turns off the tractor's engine.
14 Left Front Headlight Cover This cover is installed below the dash and conceals
the tractor's wiring harnesses.
TableOperation-2-1InstrumentPanelDescription-Ford2.5L(Continued)
No. Name Description
To Next Page
