V02.00 | 2019/11
65
Configuring the EtherNet/IP™ Slave (Device)
Configure EtherNet/IP™ Slave device at interface eth0 as described under "Commission-
ing TBEN-L...-PLC-... as Ethernet PROFINET Device" [}58].
7.3.15 Commissioning TBEN-L...-PLC-... as CANopen Manager
Properties
Max. number of devices 127
Input data max. 8 kB
Output data max. 8 kB
Configuring the CANopen Manager
ü The CANopen Manager from 3S - Smart Software Solutions GmbH is used.
Add the CANopen Manager to the CANbus using the Add Device function and configure
it.
Fig.69: Adding the CANopen Manager
