TYM T723 User Manual

(2) installation of each sub-assembled shaft.
a. Refer to the description for all parts around the front transmission
Fig.5-29
5-14
c. Installation of the main change gears and the reverse gears.
Install each sub-assembled shift into the reverse metal.
b. Installation of the creep parts in the reverse metal
1
Snap ring
Note : Be careful direction of the oil groove (to direction of the gear)
Snap ring
Reverse change
Main change
Creep gears
PTO shaft
Drive shaft
Reverse
gears
Main change gears
A
A : Direction of
the oil groove
Fig.5-27
Fig.5-28
