RF POWER SUPPLY and MATCHINGBOX
Figure 4-31 Current time configuration screen (P17)
Displays and configures the current time.
Displays the RF generator model.
Displays the software version.
Displays the FBUS software version
* When the breaker is turned on, the above current time configuration screen may be displayed.
It is displayed if the system is not powered for two weeks or longer after the breaker is turned
off
Figure 4-32 ALARM log screen (P18)
Displays the time and alarm name when an alarm occurs.
* Stores up to the past 16 occurrences.
Pf detection value when the alarm occurred
Pr detection value when the alarm occurred
TUNE position value when the alarm occurred
MATCH position value when the alarm occurred
VPP voltage detection value when the alarm occurred
VDC voltage detection value when the alarm occurred
