Page 12 of 39 Rev. 13
Post charge current delay mn 22 34 2 R/W note(4)
Post charge current Percentage % 23H 35 1 R/W note(3)
Equalize safety time (Eq T security) H 23L 35 1 R/W note(3)
DC output voltage temperature compensation
% 24 36 2 R/W note(6)
DC output current temperature compensation (TCompAmp)
% 25H 37 1 R/W note(3)
Current temperature threshold (Tref) °C 25L 37 1 R/W note(3)
Charger mode enabling 26 38 2 W note(21)
password 27 39 2 W note(4)
Alarms status 28 40 2 R note(11)
Alarm status 29 41 2 R note(12)
Alarms authorization (ON/OFF) 2A 42 2 R/W note(13)
Alarm authorization (ON/OFF) 2B 43 2 R/W note(14)
Alarms Relays latch authorization 2C 44 2 R/W note(15)
Alarms Relays latch authorization 2D 45 2 R/W note(16)
Alarm messages latch authorization 2E 46 2 R/W note(17)
Alarm messages latch authorization 2F 47 2 R/W note(18)
Alarm failsafe 30 48 2 R/W note(19)
Alarms failsafe 31 49 2 R/W note(20)
Rectifier high volts alarm level V 32 50 2 R/W note(1)
Battery high volts alarm level V 33 51 2 R/W note(1)
Rectifier low volts level V 34 52 2 R/W note(1)
Battery low volts level V 35 53 2 R/W note(1)
High volts shutdown level V 36 54 2 R/W note(1)
End of Discharge level V 37 55 2 R/W note(1)
Negative Ground fault alarm level mA 38 56 2 R/W note(1)
Positive ground fault level mA 39 57 2 R/W note(1)
Control board & inside high temperature level °C 3A 58 2 R/W note(4)
Battery high temperature level °C 3B 59 2 R/W note(4)
Battery low temperature level °C 3C 60 2 R/W note(4)
AC high volts alarm level V 3D 61 2 R/W note(1)
AC low volts alarm level V 3E 62 2 R/W note(1)
High DC current alarm level A 3F 63 2 R/W note(1)
Low DC current alarm level A 40 64 2 R/W note(1)
High ripple alarm level V 41 65 2 R/W note(1)
Cell failure alarm level V 42 66 2 R/W note(1)
Delay to initiate Rectifier high volts alarm (time) S 43H 67 1 R/W note(3)
Delay to initiate Battery high volts alarm (time) S 43L 67 1 R/W note(3)
Delay to initiate Rectifier low volts alarm (time) S 44H 68 1 R/W note(3)
Delay to initiate Battery low volts alarm (time) S 44L 68 1 R/W note(3)
Delay to initiate High volts shutdown alarm (time) S 45H 69 1 R/W note(3)
Delay to initiate End of Discharge alarm (time) S 45L 69 1 R/W note(3)
Delay to initiate Negative Ground fault alarm (time) S 46H 70 1 R/W note(3)
Delay to initiate Positive ground fault alarm (time) S 46L 70 1 R/W note(3)
Delay to initiate AC fail alarm (time) S 47H 71 1 R/W note(3)
Delay to initiate Rectifier alarm (time) S 47L 71 1 R/W note(3)
Delay to initiate Control board & inside high temperature
alarm (time)
S 48H 72 1 R/W note(3)
Delay to initiate Battery high temperature alarm (time) S 48L 72 1 R/W note(3)
Delay to initiate Battery low temperature alarm (time) S 49H 73 1 R/W note(3)
Delay to initiate AC high volts alarm (time) S 49L 73 1 R/W note(3)
Delay to initiate AC low volts alarm (time) S 4AH 74 1 R/W note(3)
Delay to initiate High DC current alarm (time) S 4AL 74 1 R/W note(3)
