Page 13 of 39 Rev. 13
Delay to initiate Low DC current alarm (time) S 4BH 75 1 R/W note(3)
Delay to initiate High ripple alarm alarm (time) S 4BL 75 1 R/W note(3)
Reserved
Delay to initiate Cell failure alarm alarm (time) S 4CL 76 1 R/W note(3)
Rectifier high volts alarm relay/ Battery high volts alarm
relay
4DH 77 1 R/W note(5)
Rectifier low volts relay/ Battery low volts alarm relay 4DL 77 1 R/W note(5)
High volts shutdown relay/ End of Discharge relay 4EH 78 1 R/W note(5)
Negative Ground fault alarm relay/ Positive ground fault
relay
4EL 78 1 R/W note(5)
AC fail alarm relay/ Rectifier alarm relay 4FH 79 1 R/W note(5)
Control board & inside high temperature relay/
Battery high temperature relay
4FL 79 1 R/W note(5)
Battery low temperature relay 50H 80 1 R/W note(3)
AC high volts alarm relay/ AC low volts alarm relay 50L 80 1 R/W note(5)
High DC current relay/ Low DC current relay 51H 81 1 R/W note(5)
High ripple alarm relay 51L 81 1 R/W note(3)
Equalize alarm relay 52H 82 1 R/W note(3)
Cell failure alarm relay 52L 82 1 R/W note(3)
Year 53H 83 1 R/W note(0)
Month 53L 83 1 R/W note(0)
Day 54H 84 1 R/W note(0)
Hour 54L 84 1 R/W note(0)
Minute 55H 85 1 R/W note(0)
Second 55L 85 1 R/W note(0)
Input contact state 56H 86 1 R/W note(3)
Input contact preset function 1/2 56L 86 1 R/W note(5)
Input contact preset function 3/4 57H 87 1 R/W note(5)
Input contact message assignment # 1/2 57L 87 1 R/W note(5)
Input contact message assignment # 3/4 58H 88 1 R/W note(5)
Input contact relay assignment # 1/2 58L 88 1 R/W note(5)
Input contact relay assignment # 3/4 59H 89 1 R/W note(5)
Battery test fail alarm relay / Battery test relay 59L 89 1 R/W note(5)
Battery test mode 5AH 90 1 R/W note(3)
Alarms Reset 5AL 90 1 note(3)
Reference current (battery test) A 5B 91 2 R/W note(1)
Reference voltage (battery test) V 5C 92 2 R/W note(1)
Reference time (battery test) mn 5D 93 2 R/W note(4)
Reserved 5E 94 2
Reserved 5F 95 2
Message10 60 96 2 R/W note(4)
Message11 61 97 2 R/W note(4)
Message12 62 98 2 R/W note(4)
Message13 63 99 2 R/W note(4)
Message14 64 100 2 R/W note(4)
Message15 65 101 2 R/W note(4)
Message16 66 102 2 R/W note(4)
Message17 67 103 2 R/W note(4)
Message20 68 104 2 R/W note(4)
Message21 69 105 2 R/W note(4)
Message22 6A 106 2 R/W note(4)
Message23 6B 107 2 R/W note(4)
