Page 24 of 39 Rev. 13
Object 30 variation 00 (Analog input all variation)
Default: Object 30 variation 04 (16-Bit analog input without status)
Request
(slave must parse)
Response
(master must parse)
Codes
function
Codes Qual (hex) Codes
function
Codes Qual (hex)
1 read 00,01,06 129-read 00,01
Po
int
Signification Unit Note
0 Unused
1 Rectifier voltage Volt note(1)
2 Rectifier current Ampere note(1)
3 Battery current Ampere note(2)
4 AC volt phase 1 Volt note(1)
5 AC volt phase 2 Volt note(1)
6 AC volt phase 3 Volt note(1)
7 AC current phase 1 Ampere note(1)
8 AC current phase 2 Ampere note(1)
9 AC current phase 3 Ampere note(1)
10 Battery temperature °C note(22)
11 Control board & inside temperature °C note(22)
12 AC frequency Hertz note(1)
