Page 25 of 39 Rev. 13
Object 40 variation 0 (Analog output all variation)
Default: Object 40 variation 02 (16-Bit analog output with status)
Request
(slave must parse)
Response
(master must parse)
Codes function Codes Qual (hex) Codes function Codes Qual (hex)
1 read 00,01,06 129-read 00,01
Point Signification Unit Note
0 Unused
1 Float voltage Volt note(1)
2 Equalize voltage Volt note(1)
3 Float Current limit Ampere note(1)
4 Equalize Current limit Ampere note(1)
5 Unused
6 Nominal output voltage Volt note(1)
7 Nominal output current (Shunt1) Ampere note(1)
8 Formation voltage Volt note(1)
9 Formation current Ampere note(1)
10 Formation time Hours note(22)
11 Formation relay note(22)
12 Unused
13 Manual equalize time out Hours note(22)
14 Periodical equalize time out Hours note(22)
15 Periodical equalize period (delay) Days note(22)
16 DC Low volts equalize time out Hours note(22)
17 DC Low volts equalize Volt note(1)
18 AC fail equalize time out Hours note(22)
19 AC fail equalize delay Seconds note(22)
20 Refresh equalize time out Minutes note(22)
21 Refresh equalize period (delay) Hours note(22)
22 Remote equalize time out Hours note(22)
23 Current limit equalize time out Hours note(22)
24 Current limit equalize delay Seconds note(22)
25 Post Charge Voltage delay Minutes note(22)
26 Post Charge current delay Minutes note(22)
27 Post charge current Percentage % note(22)
28 Equalize safety time (Eq T security) Hours note(22)
29 Unused
30 Rectifier high volts alarm level Volt note(1)
31 Battery high volts alarm level Volt note(1)
32 Rectifier low volts level Volt note(1)
33 Battery low volts level Volt note(1)
34 High volts shutdown level Volt note(1)
35 End of Discharge level Volt note(1)
36 Negative Ground fault alarm level Mili Ampere note(1)
37 Positive ground fault level Mili Ampere note(1)
38 Control board & inside high temperature level °C note(22)
39 Battery high temperature level °C note(22)
40 Battery low temperature level °C note(22)
41 AC high volts alarm level Volt note(1)
42 AC low volts alarm level Volt note(1)
43 High DC current rectifier level Ampere note(1)
44 Low DC current rectifier level Ampere note(1)
45 High ripple alarm level % note(1)
46 Cell failure alarm level Volt note(1)
47 High DC current battery level Ampere note(1)
48 Low DC current battery level Ampere note(1)
