Page 27 of 39 Rev. 13
Object 20 variation 00 (Binary counter all variation)
Default: Object 20 variation 06 (16-Bit binary counter without status)
Request
(slave must parse)
Response
(master must parse)
Codes
function
Codes Qual (hex) Codes
function
Codes Qual (hex)
1 read 00,01,06 129-read 00,01
Point Unit Note
0 Unused
1 Equalize remaining time minutes note(22)
2 Equalize elapsed time minutes note(22)
3 Formation remaining time hours note(22)
Object 41 variation 01 (32-Bit analog OUTPUT BLOCK)
Object 41 variation 02 (16-Bit analog OUTPUT BLOCK)
Select (function 3)
Operate (function 4)
Direct operation (function 5)
Direct operation no acknowledge (function 6)
Request
(slave must parse)
Response
(master must parse)
Codes function Codes Qual (hexa) Codes
function
Codes Qual (hexa)
5
Direct operate
17 129-read echo of request
Point Address
(hex)
Variable Unit Byte Note
1 0E Float voltage V 2 note(1)
2 0F Equalize voltage V 2 note(1)
3 10 Float Current limit A 2 note(1)
4 11 Equalize Current limit A 2 note(1)
5 12 Formation voltage V 2 note(1)
6 13 Formation current A 2 note(1)
7 14H Formation relay 1 note(3)
8 15H Formation time H 1 note(3)
9 16 Charger configuration 2 Refer to
paragraph (3.5.3)
10 17 Equalize mode start 2 note(9)
11 1AH Manual equalize time H 1 note(3)
12 1AL Periodical equalize time H 1 note(3)
13 1BH Periodical equalize period (delay) D 1 note(3)
14 1BL DC Low volts equalize time out H 1 note(3)
15 1C DC Low volts equalize level V 2 note(1)
16 Reserved
17 1DH AC fail equalize time out H 1 note(3)
18 1DL AC fail equalize delay S 1 note(3)
19 1EH Refresh equalize time out mn 1 note(3)
20 1EL Refresh equalize period (delay) H 1 note(3)
