Page 28 of 39 Rev. 13
21 1F H Remote equalize time out H 1 note(3)
22 1FL Current limit equalize time out H 1 note(3)
23 20H Current limit equalize delay S 1 note(3)
24 20L Equalize termination (On/Off) 1 note(10)
25 21 Post Charge Voltage Delay mn 2 note(4)
26 Reserved
27 22 Post charge current Delay mn 2 note(4)
28 Reserved
29 23H Post charge current Percentage % 1 note(3)
30 23L Equalize safety time (Eq T security) H 1 note(3)
31 24 DC output voltage temperature compensation mV 2 note(6)
32 Reserved
33 25H DC output current temperature compensation
(TCompAmp)
% 1 note(3)
34 25L Current temperature threshold (Tref) 1 note(3)
35 26 Charger mode enabling 2 note(21)
36 27 password 2 note(4)
37 2A Alarms authorization (ON/OFF) 2 note(13)
38 2B Alarm authorization (ON/OFF) 2 note(14)
39 2C Alarms Relays latch authorization 2 note(15)
40 2D Alarms Relays latch authorization 2 note(16)
41 2E Alarm messages latch authorization 2 note(17)
42 2F Alarm messages latch authorization 2 note(18)
43 30 Alarm failsafe 2 note(19)
44 31 Alarms failsafe 2 note(20)
45 32 Rectifier high volts alarm level V 2 note(1)
46 33 Battery high volts alarm level V 2 note(1)
47 34 Rectifier low volts level V 2 note(1)
48 35 Battery low volts level V 2 note(1)
49 36 High volts shutdown level V 2 note(1)
50 37 Low volts disconnect level V 2 note(1)
51 38 Negative Ground fault alarm level mA 2 note(1)
52 39 Positive ground fault level mA 2 note(1)
53 3A Control board & inside high temperature level °C 2 note(4)
54 3B Battery high temperature level °C 2 note(4)
55 3C Battery low temperature level °C 2 note(4)
56 3D AC high volts alarm level V 2 note(1)
57 3E AC low volts alarm level V 2 note(1)
58 3F High DC current alarm level A 2 note(1)
59 40 Low DC current alarm level A 2 note(1)
60 41 High ripple alarm level V 2 note(1)
61 42 Cell failure alarm level V 2 note(1)
62 Reserved
63 43H Delay to initiate Rectifier high volts alarm (time) S 1 note(3)
64 43L Delay to initiate Battery high volts alarm (time) S 1 note(3)
65 44H Delay to initiate Rectifier low volts alarm (time) S 1 note(3)
66 44L Delay to initiate Battery low volts alarm (time) S 1 note(3)
67 45H Delay to initiate High volts shutdown alarm (time) S 1 note(3)
68 45L Delay to initiate End of Discharge alarm (time) S 1 note(3)
69 46H Delay to initiate Negative Ground fault alarm (time) S 1 note(3)
70 46L Delay to initiate Positive ground fault alarm (time) S 1 note(3)
71 47H Delay to initiate AC fail alarm (time) S 1 note(3)
72 47L Delay to initiate Rectifier alarm (time) S 1 note(3)
