Page 29 of 39 Rev. 13
73 48H Delay to initiate Control board & inside high temperature
alarm (time)
S 1 note(3)
74 48L Delay to initiate Battery high temperature alarm (time) S 1 note(3)
75 49H Delay to initiate Battery low temperature alarm (time) S 1 note(3)
76 49L Delay to initiate AC high volts alarm (time) S 1 note(3)
77 4AH Delay to initiate AC low volts alarm (time) S 1 note(3)
78 4AL Delay to initiate High DC current alarm (time) S 1 note(3)
79 4BH Delay to initiate Low DC current alarm (time) S 1 note(3)
80 4BL Delay to initiate High ripple alarm (time) S 1 note(3)
81 Reserved
82 4CL Delay to initiate Cell failure alarm (time) S 1 note(3)
83 4DH Rectifier high volts alarm relay/ Battery high volts alarm
relay
1 note(5)
84 4DL Rectifier low volts relay/ Battery low volts alarm relay 1 note(5)
85 4EH High volts shutdown relay/ End of Discharge relay 1 note(5)
86 4EL Negative Ground fault alarm relay/ Positive ground fault
relay
1 note(5)
87 4FH AC fail alarm relay/ Rectifier alarm relay 1 note(5)
88 4FL Control board & inside high temperature relay/
Battery high temperature relay
1 note(5)
89 50H Battery low temperature relay 1 note(3)
90 50L AC high volts alarm relay/ AC low volts alarm relay 1 note(5)
91 51H High DC current relay/ Low DC current relay 1 note(5)
92 51L High ripple alarm relay 1 note(3)
93 52H Equalize alarm relay 1 note(3)
94 52L Cell failure alarm relay 1 note(3)
95 53H Year 1 note(0)
96 53L Month 1 note(0)
97 54H Day 1 note(0)
98 54L Hour 1 note(0)
99 55H Minute 1 note(0)
100 Reserved
101 Reserved
102 56L Input contact preset function 1/2 1 note(5)
103 57H Input contact preset function 3/4 1 note(5)
104 57L Input contact message assignment # 1/2 1 note(5)
105 58H Input contact message assignment # 3/4 1 note(5)
106 58L Input contact relay assignment # 1/2 1 note(5)
107 59H Input contact relay assignment # 3/4 1 note(5)
108 59L Battery test fail alarm relay / Battery test relay 1 note(5)
109 5AH Battery test mode 1 note(3)
110 5AL Alarms Reset 1 Refer to
paragraph (3.5.4)
111 5B Reference current (battery test) A 2 note(1)
112 5C Reference voltage (battery test) V 2 note(1)
113 5D Reference time (battery test) mn 2 note(4)
114 60 Message10 2 note(4)
115 61 Message11 2 note(4)
116 62 Message12 2 note(4)
117 63 Message13 2 note(4)
118 64 Message14 2 note(4)
119 65 Message15 2 note(4)
120 66 Message16 2 note(4)
