Rev.B15
Pg. 28 di 80
Digital outputs Digital inputs Fieldbus module
MSB Bytes 0 -......
(1) The wording may vary according to the used protocol and according to the selected language, if
supported by the configuration file.
+++++
The physical position of the modules determines the rising of the given Bytes, according to a
sequence that always evolves from the fieldbus module to the left.
A specific sequence of the module installation must be observed to ensure that the system works
properly.
First the input modules (TC8I412, TC16I812, TC8I808, TCR32ID), then the additional modules
TCR1616 (discontinues), after the output modules (TC8U412 or TCR32UD) and in the end the
possible modules for the electric clamps (TC-ECSM, TC-2ECD).
Product identification label
Model Firmware Revision Protection degree
Supply voltage Production year
Serial number
MAC ID (when so required)
