UniVer TC User Manual

Rev.B15
Pg. 6 di 80
Codification key
(1) Only for DeviceNet and Profibus.
(2) This solution consists of an additional module (TCxUS78) equipped with 7/8 connectors (the POWER SUPPLY
connector of the standard module is removed)
(3) From 2022 no longer available.
SERIES
TC I/O Module + Valve interface
TE
x
7 Auxiliary connection 7/8
(2)
M
FIELDBUS
C
D
P
PN
EN
EC
LKA
LKB
DIGITAL INPUTS
Input connector dimension
S
H
H2
8
DIGITAL OUTPUTS
EXPANSIONS Digital inputs and outputs
32IN
64IN
32UD
64UD
1616
3232
6464
A1C
A2C
M12 High-Density digital input (TC16I812 8x2)
2 Modules TCR32UD 16+16 digital outputs (2xDSUB 25)
1 Module TCR1616 16 digital inputs + 16 digital outputs (2xDSUB 25) (3)
1 Module TCR32ID + 1 Module TCR32UD
I/O Module
Standard connection M12
Multibus connection M23
(1)
CANopen 64+64 I/O
S
08
Devicenet 64+64 I/O
TC
x
EN
08
Profibus DP 64+64 I/O
EtherNet/IP 64+88 I/O
N° 00-08-16-24-32-40-48-56-64
Profinet 64+88 I/O
EtherCAT 64+88 I/O
no input module = 00
IO-Link Class A 24 Coils
IO-Link Class B 24 Coils
1 Module TC-ECSM + 1 Module TC-2ECD for 2 Electric Power Clammps
1 Module TC-ECSM + 2 Modules TC-2ECD for 4 Electric Power Clammps
no output module = 00
M12 Standard digital input (4x2)
M12 High-Density digital input (TC16I812-2F 8x2) support 2-wires electronic
Blank if there is only the expansion module
N° 00-08-16-24-32-40-48-56-64
M08 digital input (8x1)
Blank with no expansion module
2 Modules TCR32ID + 2 Modules TCR32UD
1 Module TCR32ID 16+16 digital inputs (2xDSUB 25)
2 Modules TCR32ID 16+16 digital inputs (2xDSUB 25)
1 Module TCR32UD 16+16 digital outputs (2xDSUB 25)
