Modules for electric clamps (features)

Supply unit data TC-ECSM

Supply connector Harting HAN Q 2/0 da 40A

Auxiliary LED

Power green

Electrical data

Supply connector Harting HAN Q 2/0 da 40A

Voltage for electric devices 24 Vdc +5% -15% (4)

Nominal power 32A max

Environmental conditions

Weight 450g

Module overall dimensions 55x123x75 mm

Protection degree IP 65 (with connectors) IEC 60529

Relative humidity 5 to 85% IEC 60068-2-30

Operating temperature

5°C

50°C

IEC 60068-2-1

Storage temperature

-25°C

80°C

IEC 60068-2-2

Vibrations 5g tested 10-500Hz IEC 60068-2-6

Shock 22g IEC 60068-2-27

Control unit data TC-2ECD

Device connector

Circular M12 Female 4 pin T code motor supply and

controls.

Circular M12 Female 5 pin A code for logic and inputs power

supplyi.

System LED

CLOSED Green

OPEN Green

FAULT Red

CLOSING Yellow

OPENING Yellow

Auxiliary LED

Power Green

Functions

Optimized power control through automatic delayed

command of the clamping devices.

(5)

Electrical data

Motor power connector Circular M12 male 4 pin T code

Motor supply voltage 24 Vdc +5% -15% (4)

Nominal power 8A max

Connector for logic supply and signals Circular M12 male 5 pin A code

Logic voltage (VLS24) 24 Vdc ±15%

Maximal logic power (VLS24) 175mA max – overload protection (2)

Mangeable devices 2 devices – clamp size 40/50/63/80

Manageable digital command outputs 4 digital outputs (open-close commands for each device)

Mangeable digital inputs 6 digital inputs (open, close, error for each device)
