Error codes - Profinet, EtherNet/IP, EtherCAT
ON/Diag
Color Status Meaning
1 Flashing
Lack of general power supply (24VA).
2 Flashings
One or more output are in short circuit or overloaded.
3 Flashings
Attention, high level of disturbance.
4 Flashings
Module error (one or more modules are not working).
5 Flashings
No inputs or outputs module detected.
6 Flashings
Reserved (WDT).
7 Flashings
Reserved.
8 Flashings
Reserved (IO Configuration Fail).
9 Flashings
Lack of supply +24V for input (overload)
10 Flashings
Lack of module power supply.
11 Flashings
Reserved (EEprom Fail).
12 Flashings
Electric clamp in error.
13 Flashings
Short circuit or overload on the outputs of the electric clamps.
1 Flashing
Reserved (FW Cookie not valid).
2 Flashings
Reserved (Map Channel not valid).
3 Flashings
Reserved (FW not valid).
4 Flashings
Reserved (Hand Shake Invalid).
5 Flashings
Reserved (Configuration Failed).
6 Flashings
Reserved (Lock Failed).
7 Flashings
Reserved (Register Failed).
8 Flashings
Reserved (Device Ready Timeout).
