UniVer TC User Manual

Rev.B15
Pg. 66 di 80
Error codes of the EtherCAT diagnostics messaging
The emergency message consists of 5 bytes with the data as shown below:
Composition of the emergency message
Byte 0 1 2 3 4
Content
Manufacturer specific error fields
Main
Diagnostics
0000-0000 0000-0000 0000-0000 0000-0000
Module No.2
Module No.1
Module No.4
Module No.3
Module No.6
Module No.5
Module No.8
Module No.7
MANUFACTURER SPECIFIC ERROR FIELDS
BITS OF THE MAIN DISGNOSTICS (BYTE 0)
Bit Name Description
0
24V Main power loss
This bit at 1 indicated the lack of the VA24 power supply (pin4 of the power
connector) In this condition the valve coils will not be powered even if the
command is active.
1
Module fail
This bit at 1 indicates that the module is faulty (replace the module).
2
Output fail
This bit at 1 indicated that one or more outputs are overloaded or in short circuit,
this applies both to the integrated manifold and for the output modules (1).
3
High noise level
This bit at 1 indicates that a communication error has been detected on the
internal bus, caused by the high level of noise, due to bad wiring, lack of
grounding or capacitive coupling of the connecting cables.
4
Input power loss
This bit at 1 indicates an overload or a short circuit in one or more connectors of
the input module.
5
Clamp Error
This bit at 1 indicates that one or more electric clamps are in error.
6
Input modules or
output modules
This bit at 0 indicates that the content of the message refers ot input modules.
This bit at 1 indicates that the content of the messages refers to the output
modules (3).
7
Module info Monitor
This bit at 1 indicates that an extended module diagnostics is available.
NIBBLES OF THE INPUT AND OUTPUT MODULES (BYTE 1….4)
Binary Description
0000
This value indicates that no error is present.
0001
This value indicates the lack of power supply (VA24).
0010
This value indicates that one or more outputs are overloaded or in short circuit. (2)
0011
This value indicates that a communication error has been detected on the internal bus, caused by a
high level of noise, due to bad wiring, lack of grounding, or capacitive coupling of the connection
cables.
0100
This value indicates a module failure.
0101
This value indicates an overload or short circuit in one or more connectors of the input modules.
0110
This value indicates that one or more electric clamps are in error (FAULT output active).
0111
This value indicates that one or more control outputs for the electric clamps are overloaded or in short
circuit.
1000 - 1111
Not yet assigned.
