Allocation of Byte/Bit of electric clamp modules
Byte-Bit Inputs Byte-Bit outputs
Module Clamp
Opening Closing Fault Opening Closing
1
1
0-0 0-1
0-2 0-0 0-1
2
0-3 0-4
0-5 0-2 0-3
2
3
1-0 1-1
1-2 0-4 0-5
4
1-3 1-4
1-5 0-6 0-7
3
5
2-0 2-1
2-2 1-0 1-1
6
2-3 2-4
2-5 1-2 1-3
4
7
3-0 3-1
3-2 1-4 1-5
8
3-3 3-4
3-5 1-6 1-7
Input and Output bytes of electric power clamps modules are subsequent to the input and
output modules already in the system.
