UniVer TC User Manual

Rev.B15
Pg. 69 di 80
From the master configuration programme it is also possible to enable or sable the generation of some
errors and to set some device options.
If the option “Other Module info” is disabled, no module extended error will be generated.
Parameters table
Diag: 24V Main Power Loss
Enable or disable the generation of the diagnostics in case of a power
failure for the outputs (VA24).
Diag: Module fail
Enable or disable the generation of the diagnostics in case or module
failure.
Diag: Output fail
Enable or disable the generation of the diagnostics in case of overload
or short circuit of the outputs.
Diag: High Noise level
Enable or disable the generation of the diagnostics in case of detection
of a high level of noise.
Diag: 24V Input power loss
Enable or disable the generation of the diagnostics in case of a power
failure on the input modules.
Input response time
Slow: input filter for very noisy environment (> 50mS).
Fast: Maximum sampling frequency of the inputs (< 50mS).
The time depends on the number of inputs and outputs of the system.
Default Slow.
Mode Manifold First
If True, the integrated manifold will use the first 3 bytes of the
assigned address.
If False, the integrated manifold will use the last 3 bytes of the
assigned address.
Diag: Other Module info If Able a diagnostics will be generated for each sub module.
Clamp Lag time
Indicates the lag time between the command of a electric clamp and
the next one (25…400mS in steps of 25mS).
Default 150mS.
Clamp Activated at the same
Time
Indicates the number or clamps that can be activated in the same
moment (1…8).
Default 8.
Note: if not configured, all the diagnostics functions are enabled.
The procedure for modifying the configuration parameters depends on the master software used.
In the next page you can see an example of the menu that appears in “Anybus Tools” “Slave Properties”
“Parameter assignment”.
