GUID-2B1A1B70-F454-4DD2-8498-15F6FA9B3AAB
1. Fan speed control knob
2. Display
3. Air conditioning ON/OFF
4. Temperature control knob
• To activate the automatic air conditioning system, turn the fan speed control
knob to the AUTO position.
When the automatic air conditioning and the AC compressor are active, the
LED next to the air conditioning ON/OFF button is lit and the indicator AUTO
is shown on the display. The system regulates the fan speed automatically.
• Select the target temperature with the temperature control knob.
The target temperature is shown on the display.
• To reach the maximum cooling effect, turn the knob to the extreme
cooling position.
Indicator LO is shown on the display.
• To reach the maximum heating effect, turn the knob to the extreme
heating position.
Indicator HI is shown on the display.
• To regulate the fan speed manually, turn the fan speed control knob
clockwise to the target speed.
The fan speed is shown on the display.
• To deactivate the air conditioning system, turn the fan control knob to the
OFF position.
3.6.4.3 Using ECO mode
Use the air conditioning ECO mode to regulate the cab temperature without the
AC compressor. In the ECO mode the system tries to achieve the target
temperature by adjusting the water valve and fan speed. This mode saves both
the battery power and fuel.
3. Operation
- 86 -
