3.8.5 Adjusting the power shuttle engagement speed
You can adjust the power shuttle engagement speed through the tractor terminal
transmission settings.
The index determines how quickly the torque of the power shuttle increases to
the maximum value when the clutch is engaged. The index affects both the F
(forward) and R (reverse) clutch engagements. The value ranges from 1–10,
where:
• 1 = very slow engagement
• 10 = very quick engagement
3
START
x
4
x
C D
AUTO
AUTO 2
F R
1150 2050
GUID-B442195C-4000-4B2A-BC31-787CC8BACBA8
1. Power shuttle engagement speed setting
1. Press ESC.
2. Navigate to the menu 2 with the up and down arrow buttons.
3. Press the right arrow button to enter the transmission settings view.
NOTE: When the power shuttle lever is in the parking brake position (P), you
can enter the transmission settings view by pressing the preprogramming
button.
4. Select the wanted memory slot with the left and right arrow buttons.
5. Move the navigation box to the power shuttle engagement speed setting
with the up and down arrow buttons or by rotating the selector for the
predefined factory/user settings.
6. Press the right arrow button, OK button or the selector for the predefined
factory/user settings.
7. Set the value for the power shuttle engagement speed by pressing the up or
down arrow button or by rotating the selector for the predefined factory/user
settings.
8. Press the left arrow button or selector for the predefined factory/user settings
to return to the transmission settings view main level.
With a short press of the ESC button you can return to the menu 2. A long press
of the ESC button returns to the previously active drive display.
3. Operation
- 95 -
