1. Relay K8M
4.8.6.9 Fuses and relays in the engine electric centre
Fuses and relays in the engine electric centre are listed in the following tables.
The fuse diagram is on the reverse side of the electric centre cover. The engine
electric centre contains 10 fuses and 2 empty places for spares. The nominal
current rating of the fuses is 3-25 A.
4. Maintenance
- 398 -
