6.13.3.1 Valves for auxiliary hydraulics
Rear, standard • Two double-acting valves with adjustable electric
control
• One on/off valve that controls the hydraulic top
link
Rear, optional
• Three double-acting valves with adjustable
electric control
• Four double-acting valves with adjustable electric
control
• Five double-acting valves with adjustable electric
control
• Four double-acting valves with adjustable electric
control and Power Beyond coupling
• One on/off valve plugged or with a solid
connection for the hydraulic lift link or for the
Hydraulic pick-up hitch
• Front linkage shut-off valve
Front, optional • Two double-acting valves with adjustable electric
control. Additionally one of the following options
can be fitted as optional:
• Front loader
• Front loader readiness
• Front linkage and front quick couplings
• Three double-acting valves with adjustable
electric control. Additionally one of the following
options can be fitted as optional:
• Front loader
• Front loader readiness
• Front linkage and front quick couplings
• Three double-acting valves with adjustable
electric control and two 6/2 valves. Additionally
one of the following options can be fitted as
optional:
• Front loader
• Front loader readiness
• Front linkage and front quick couplings
• Front loader, front linkage and front quick
couplings
• Front loader readiness, front linkage and
front quick couplings
On/Off valve (optional)
Type Directional control valve
Maximum capacity 11 l/min
Control With the rocker switch
Double-acting valve
Type Directional control valve including Zero leak
Maximum capacity 80-90 l/min
Control Electrically adjusted CAN-bus valves
• With joystick
• Rear valves 1 and 2
• Front valves 1F and 2F
• With control levers
• Rear valves 3, 4 and 5
• Front valve 3F
Quick couplings
Standard ISO7241-1 Series A
6. Technical specifications
- 434 -
