6.13.5 Front linkage
Lifting force 50 kN
Number of lifting cylinders 2
Diameter of the lifting cylinders 90 mm
Lifting range at the end of the lifting links 870 mm
Quick coupling hooks Category 3/2
6.13.6 Towing devices
6.13.6.1 Pick-up hitch
Maximum permissible vertical loading
3000 kg
1)
Pick-up hitch height from the ground (lowest position
and tyre radius R=925 mm)
216mm
D-value
2)
81.8 kN
Drawbar eye standard ISO 5692-1 or ISO 20019
1)
The maximum axle loading must not be exceeded
2)
Mathematically established horizontal force
6.13.6.2 Euro pick-up hitch
Hitch or drawbar
Replaceable
Maximum permissible vertical loading for the tow
hook and K80 ball hitch
3000 kg
Pick-up hitch height from the ground (lowest position
and tyre radius R=925 mm)
208 mm
D-value Hook: 87.7 kN
K80 ball: 84.8 kN
Drawbar: 71.8 kN
Drawbar pin diameter
32 mm
Drawbar eye standard for tow hook ISO 5692-1 or ISO 20019
Drawbar eye standard for drawbar ISO 5692-1, ISO 5692-2, ISO 8755, ISO 1102
Drawbar eye standard for 80 mm ball hitch ISO 24347
The horizontal distances of the pulling point from the power take-off (PTO) shaft
and the maximum vertical loadings:
6. Technical specifications
- 436 -
